Reductor melcat NMRW 90 i=25 100B5 H35

Cod: NMRW90 25 100B5

Reductor melcat NMRW 90 i=25 100B5 H35 de calitate superioara, la preturi competitive, disponibile in stoc sau la comanda!

Preț la cerere

Trimiteți cererea și primiți oferta cu prețul și termenul de livrare, de obicei în aceeași zi.

Prețurile sunt vizibile pentru clienții cu cont aprobat. Autentificați-vă

Sau sunați: 0746 556 600

Documente tehnice

Fișă tehnică SATI (VP/VI)

Specificații tehnice

Raport	25
Diametru ax motor	28 mm
Diametru flanșă	250 mm
Diametru ax ieșire standard	35 mm
Gabarit motor	100
Tip flanșă	B5 Flansa mare
Unitate de măsură	buc

Cote

Dimensiunile din vizualizarea 3D, în milimetri, fiecare cu sursa ei.

Dimensiune	Valoare	Sursa
Înălțime totalăCatalog reductoare SATI, p. 69	238	Catalog reductoare SATI, p. 69
Înălțimea axului de ieșireCatalog reductoare SATI, p. 69	103	Catalog reductoare SATI, p. 69
LungimeCatalog reductoare SATI, p. 69	208	Catalog reductoare SATI, p. 69
LățimeCatalog reductoare SATI, p. 69	130	Catalog reductoare SATI, p. 69
Distanța între axeCatalog reductoare SATI, p. 69	90	Catalog reductoare SATI, p. 69
Ax de ieșire tubular, canal de panăCatalog reductoare SATI, p. 69	Ø35 H8, 10 × 38,3	Catalog reductoare SATI, p. 69
Lungimea axului tubularCatalog reductoare SATI, p. 69	140	Catalog reductoare SATI, p. 69
Centraj de ieșire și găuriCatalog reductoare SATI, p. 69	Ø110 h8, 8 × M10×18 / Ø130	Catalog reductoare SATI, p. 69
Flanșă de intrare 100 B5: diametru exterior (P)Catalog reductoare SATI, p. 26	Ø250	Catalog reductoare SATI, p. 26
Flanșă de intrare: diametru de divizare găuri (M)Catalog reductoare SATI, p. 26	Ø215	Catalog reductoare SATI, p. 26
Flanșă de intrare: diametru centraj (N)Catalog reductoare SATI, p. 26	Ø180	Catalog reductoare SATI, p. 26
Axul de ieșire la flanșa de intrareCatalog reductoare SATI, p. 69	129,5	Catalog reductoare SATI, p. 69
Găuri tălpi și entraxeCatalog reductoare SATI, p. 69	4 × Ø13, 140 × 100	Catalog reductoare SATI, p. 69

Variante: Reductoare melcate 90

Cod	Denumire	Diametru ax motor	Diametru flanșă	Gabarit motor	Raport	Tip flanșă	Preț fără TVA
NMRW90 10 100B14	Reductor melcat NMRW 90 i=10 100B14 H35NMRW90 10 100B14	28 mm	160 mm	100	10	B14 Flansa mica	La cerere
NMRW90 10 100B5	Reductor melcat NMRW 90 i=10 100B5 H35NMRW90 10 100B5	28 mm	250 mm	100	10	B5 Flansa mare	La cerere
NMRW90 10 90B14	Reductor melcat NMRW 90 i=10 90B14 H35NMRW90 10 90B14	24 mm	140 mm	90	10	B14 Flansa mica	La cerere
NMRW90 10 90B5	Reductor melcat NMRW 90 i=10 90B5 H35NMRW90 10 90B5	24 mm	200 mm	90	10	B5 Flansa mare	La cerere
NMRW90 100 80B14	Reductor melcat NMRW 90 i=100 80B14 H35NMRW90 100 80B14	19 mm	120 mm	80	100	B14 Flansa mica	La cerere
NMRW90 100 80B5	Reductor melcat NMRW 90 i=100 80B5 H35NMRW90 100 80B5	19 mm	200 mm	80	100	B5 Flansa mare	La cerere
NMRW90 100 90B14	Reductor melcat NMRW 90 i=100 90B14 H35NMRW90 100 90B14	24 mm	140 mm	90	100	B14 Flansa mica	La cerere
NMRW90 100 90B5	Reductor melcat NMRW 90 i=100 90B5 H35NMRW90 100 90B5	24 mm	200 mm	90	100	B5 Flansa mare	La cerere
NMRW90 15 100B14	Reductor melcat NMRW 90 i=15 100B14 H35NMRW90 15 100B14	28 mm	160 mm	100	15	B14 Flansa mica	La cerere
NMRW90 15 100B5	Reductor melcat NMRW 90 i=15 100B5 H35NMRW90 15 100B5	28 mm	250 mm	100	15	B5 Flansa mare	La cerere
NMRW90 15 90B14	Reductor melcat NMRW 90 i=15 90B14 H35NMRW90 15 90B14	24 mm	140 mm	90	15	B14 Flansa mica	La cerere
NMRW90 15 90B5	Reductor melcat NMRW 90 i=15 90B5 H35NMRW90 15 90B5	24 mm	200 mm	90	15	B5 Flansa mare	La cerere
NMRW90 20 100B14	Reductor melcat NMRW 90 i=20 100B14 H35NMRW90 20 100B14	28 mm	160 mm	100	20	B14 Flansa mica	La cerere
NMRW90 20 100B5	Reductor melcat NMRW 90 i=20 100B5 H35NMRW90 20 100B5	28 mm	250 mm	100	20	B5 Flansa mare	La cerere
NMRW90 20 90B14	Reductor melcat NMRW 90 i=20 90B14 H35NMRW90 20 90B14	24 mm	140 mm	90	20	B14 Flansa mica	La cerere
NMRW90 20 90B5	Reductor melcat NMRW 90 i=20 90B5 H35 cu flansa mareNMRW90 20 90B5	24 mm	200 mm	90	20	B5 Flansa mare	La cerere
NMRW90 25 100B14	Reductor melcat NMRW 90 i=25 100B14 H35NMRW90 25 100B14	28 mm	160 mm	100	25	B14 Flansa mica	La cerere
NMRW90 25 100B5	Reductor melcat NMRW 90 i=25 100B5 H35Produsul afișatNMRW90 25 100B5	28 mm	250 mm	100	25	B5 Flansa mare	La cerere
NMRW90 25 80B14	Reductor melcat NMRW 90 i=25 80B14 H35NMRW90 25 80B14	19 mm	120 mm	80	25	B14 Flansa mica	La cerere
NMRW90 25 80B5	Reductor melcat NMRW 90 i=25 80B5 H35NMRW90 25 80B5	19 mm	200 mm	80	25	B5 Flansa mare	La cerere
NMRW90 25 90B14	Reductor melcat NMRW 90 i=25 90B14 H35NMRW90 25 90B14	24 mm	140 mm	90	25	B14 Flansa mica	La cerere
NMRW90 25 90B5	Reductor melcat NMRW 90 i=25 90B5 H35NMRW90 25 90B5	24 mm	200 mm	90	25	B5 Flansa mare	La cerere
NMRW90 30 100B14	Reductor melcat NMRW 90 i=30 100B14 H35NMRW90 30 100B14	28 mm	160 mm	100	30	B14 Flansa mica	La cerere
NMRW90 30 100B5	Reductor melcat NMRW 90 i=30 100B5 H35NMRW90 30 100B5	28 mm	250 mm	100	30	B5 Flansa mare	La cerere
NMRW90 30 80B14	Reductor melcat NMRW 90 i=30 80B14 H35NMRW90 30 80B14	19 mm	120 mm	80	30	B14 Flansa mica	La cerere
NMRW90 30 80B5	Reductor melcat NMRW 90 i=30 80B5 H35NMRW90 30 80B5	19 mm	200 mm	80	30	B5 Flansa mare	La cerere
NMRW90 30 90B14	Reductor melcat NMRW 90 i=30 90B14 H35NMRW90 30 90B14	24 mm	140 mm	90	30	B14 Flansa mica	La cerere
NMRW90 30 90B5	Reductor melcat NMRW 90 i=30 90B5 H35NMRW90 30 90B5	24 mm	200 mm	90	30	B5 Flansa mare	La cerere
NMRW90 40 100B14	Reductor melcat NMRW 90 i=40 100B14 H35NMRW90 40 100B14	28 mm	160 mm	100	40	B14 Flansa mica	La cerere
NMRW90 40 100B5	Reductor melcat NMRW 90 i=40 100B5 H35NMRW90 40 100B5	28 mm	250 mm	100	40	B5 Flansa mare	La cerere
NMRW90 40 80B14	Reductor melcat NMRW 90 i=40 80B14 H35NMRW90 40 80B14	19 mm	120 mm	80	40	B14 Flansa mica	La cerere
NMRW90 40 80B5	Reductor melcat NMRW 90 i=40 80B5 H35 cu flansa mareNMRW90 40 80B5	19 mm	200 mm	80	40	B5 Flansa mare	La cerere
NMRW90 40 90B14	Reductor melcat NMRW 90 i=40 90B14 H35NMRW90 40 90B14	24 mm	140 mm	90	40	B14 Flansa mica	La cerere
NMRW90 40 90B5	Reductor melcat NMRW 90 i=40 90B5 H35NMRW90 40 90B5	24 mm	200 mm	90	40	B5 Flansa mare	La cerere
NMRW90 50 80B14	Reductor melcat NMRW 90 i=50 80B14 H35NMRW90 50 80B14	19 mm	120 mm	80	50	B14 Flansa mica	La cerere
NMRW90 50 80B5	Reductor melcat NMRW 90 i=50 80B5 H35NMRW90 50 80B5	19 mm	200 mm	80	50	B5 Flansa mare	La cerere
NMRW90 50 90B14	Reductor melcat NMRW 90 i=50 90B14 H35NMRW90 50 90B14	24 mm	140 mm	90	50	B14 Flansa mica	La cerere
NMRW90 50 90B5	Reductor melcat NMRW 90 i=50 90B5 H35 cu flansa mareNMRW90 50 90B5	24 mm	200 mm	90	50	B5 Flansa mare	La cerere
NMRW90 60 80B14	Reductor melcat NMRW 90 i=60 80B14 H35NMRW90 60 80B14	19 mm	120 mm	80	60	B14 Flansa mica	La cerere
NMRW90 60 80B5	Reductor melcat NMRW 90 i=60 80B5 H35NMRW90 60 80B5	19 mm	200 mm	80	60	B5 Flansa mare	La cerere
NMRW90 60 90B14	Reductor melcat NMRW 90 i=60 90B14 H35NMRW90 60 90B14	24 mm	140 mm	90	60	B14 Flansa mica	La cerere
NMRW90 60 90B5	Reductor melcat NMRW 90 i=60 90B5 H35NMRW90 60 90B5	24 mm	200 mm	90	60	B5 Flansa mare	La cerere
NMRW90 7.5 100B14	Reductor melcat NMRW 90 i=7.5 100B14 H35NMRW90 7.5 100B14	28 mm	160 mm	100	7,5	B14 Flansa mica	La cerere
NMRW90 7.5 100B5	Reductor melcat NMRW 90 i=7.5 100B5 H35NMRW90 7.5 100B5	28 mm	250 mm	100	7,5	B5 Flansa mare	La cerere
NMRW90 7.5 90B14	Reductor melcat NMRW 90 i=7.5 90B14 H35NMRW90 7.5 90B14	24 mm	140 mm	90	7,5	B14 Flansa mica	La cerere
NMRW90 7.5 90B5	Reductor melcat NMRW 90 i=7.5 90B5 H35NMRW90 7.5 90B5	24 mm	200 mm	90	7,5	B5 Flansa mare	La cerere
NMRW90 80 80B14	Reductor melcat NMRW 90 i=80 80B14 H35NMRW90 80 80B14	19 mm	120 mm	80	80	B14 Flansa mica	La cerere
NMRW90 80 80B5	Reductor melcat NMRW 90 i=80 80B5 H35NMRW90 80 80B5	19 mm	200 mm	80	80	B5 Flansa mare	La cerere
NMRW90 80 90B14	Reductor melcat NMRW 90 i=80 90B14 H35NMRW90 80 90B14	24 mm	140 mm	90	80	B14 Flansa mica	La cerere
NMRW90 80 90B5	Reductor melcat NMRW 90 i=80 90B5 H35NMRW90 80 90B5	24 mm	200 mm	90	80	B5 Flansa mare	La cerere
VP90 10 100B14	Reductor melcat 90 i=10 100B14 H35VP90 10 100B14	28 mm	160 mm	100	10	B14 Flansa mica	La cerere
VP90 10 100B5	Reductor melcat 90 i=10 100B5 H35VP90 10 100B5	28 mm	250 mm	100	10	B5 Flansa mare	La cerere
VP90 10 90B14	Reductor melcat 90 i=10 90B14 H35VP90 10 90B14	24 mm	140 mm	90	10	B14 Flansa mica	La cerere
VP90 10 90B5	Reductor melcat 90 i=10 90B5 H35VP90 10 90B5	24 mm	200 mm	90	10	B5 Flansa mare	La cerere
VP90 100 80B14	Reductor melcat 90 i=100 80B14 H35VP90 100 80B14	19 mm	120 mm	80	100	B14 Flansa mica	La cerere
VP90 100 80B5	Reductor melcat 90 i=100 80B5 H35VP90 100 80B5	19 mm	200 mm	80	100	B5 Flansa mare	La cerere
VP90 100 90B14	Reductor melcat 90 i=100 90B14 H35VP90 100 90B14	24 mm	140 mm	90	100	B14 Flansa mica	La cerere
VP90 100 90B5	Reductor melcat 90 i=100 90B5 H35VP90 100 90B5	24 mm	200 mm	90	100	B5 Flansa mare	La cerere
VP90 15 100B14	Reductor melcat 90 i=15 100B14 H35VP90 15 100B14	28 mm	160 mm	100	15	B14 Flansa mica	La cerere
VP90 15 100B5	Reductor melcat 90 i=15 100B5 H35VP90 15 100B5	28 mm	250 mm	100	15	B5 Flansa mare	La cerere
VP90 15 90B14	Reductor melcat 90 i=15 90B14 H35VP90 15 90B14	24 mm	140 mm	90	15	B14 Flansa mica	La cerere
VP90 15 90B5	Reductor melcat 90 i=15 90B5 H35 cu flansa mareVP90 15 90B5	24 mm	200 mm	90	15	B5 Flansa mare	La cerere
VP90 20 100B14	Reductor melcat 90 i=20 100B14 H35 cu flansa micaVP90 20 100B14	28 mm	160 mm	100	20	B14 Flansa mica	La cerere
VP90 20 100B5	Reductor melcat 90 i=20 100B5 H35VP90 20 100B5	28 mm	250 mm	100	20	B5 Flansa mare	La cerere
VP90 20 90B14	Reductor melcat 90 i=20 90B14 H35VP90 20 90B14	24 mm	140 mm	90	20	B14 Flansa mica	La cerere
VP90 20 90B5	Reductor melcat 90 i=20 90B5 H35VP90 20 90B5	24 mm	200 mm	90	20	B5 Flansa mare	La cerere
VP90 25 100B14	Reductor melcat 90 i=25 100B14 H35VP90 25 100B14	28 mm	160 mm	100	25	B14 Flansa mica	La cerere
VP90 25 100B5	Reductor melcat 90 i=25 100B5 H35VP90 25 100B5	28 mm	250 mm	100	25	B5 Flansa mare	La cerere
VP90 25 80B14	Reductor melcat 90 i=25 80B14 H35VP90 25 80B14	19 mm	120 mm	80	25	B14 Flansa mica	La cerere
VP90 25 80B5	Reductor melcat 90 i=25 80B5 H35VP90 25 80B5	19 mm	200 mm	80	25	B5 Flansa mare	La cerere
VP90 25 90B14	Reductor melcat 90 i=25 90B14 H35VP90 25 90B14	24 mm	140 mm	90	25	B14 Flansa mica	La cerere
VP90 25 90B5	Reductor melcat 90 i=25 90B5 H35VP90 25 90B5	24 mm	200 mm	90	25	B5 Flansa mare	La cerere
VP90 30 100B14	Reductor melcat 90 i=30 100B14 H35VP90 30 100B14	28 mm	160 mm	100	30	B14 Flansa mica	La cerere
VP90 30 100B5	Reductor melcat 90 i=30 100B5 H35VP90 30 100B5	28 mm	250 mm	100	30	B5 Flansa mare	La cerere
VP90 30 80B14	Reductor melcat 90 i=30 80B14 H35VP90 30 80B14	19 mm	120 mm	80	30	B14 Flansa mica	La cerere
VP90 30 80B5	Reductor melcat 90 i=30 80B5 H35VP90 30 80B5	19 mm	200 mm	80	30	B5 Flansa mare	La cerere
VP90 30 90B14	Reductor melcat 90 i=30 90B14 H35VP90 30 90B14	24 mm	140 mm	90	30	B14 Flansa mica	La cerere
VP90 30 90B5	Reductor melcat 90 i=30 90B5 H35VP90 30 90B5	24 mm	200 mm	90	30	B5 Flansa mare	La cerere
VP90 40 100B14	Reductor melcat 90 i=40 100B14 H35VP90 40 100B14	28 mm	160 mm	100	40	B14 Flansa mica	La cerere
VP90 40 100B5	Reductor melcat 90 i=40 100B5 H35VP90 40 100B5	28 mm	250 mm	100	40	B5 Flansa mare	La cerere
VP90 40 80B14	Reductor melcat 90 i=40 80B14 H35VP90 40 80B14	19 mm	120 mm	80	40	B14 Flansa mica	La cerere
VP90 40 80B5	Reductor melcat 90 i=40 80B5 H35VP90 40 80B5	19 mm	200 mm	80	40	B5 Flansa mare	La cerere
VP90 40 90B14	Reductor melcat 90 i=40 90B14 H35VP90 40 90B14	24 mm	140 mm	90	40	B14 Flansa mica	La cerere
VP90 40 90B5	Reductor melcat 90 i=40 90B5 H35VP90 40 90B5	24 mm	200 mm	90	40	B5 Flansa mare	La cerere
VP90 50 80B14	Reductor melcat 90 i=50 80B14 H35VP90 50 80B14	19 mm	120 mm	80	50	B14 Flansa mica	La cerere
VP90 50 80B5	Reductor melcat 90 i=50 80B5 H35VP90 50 80B5	19 mm	200 mm	80	50	B5 Flansa mare	La cerere
VP90 50 90B14	Reductor melcat 90 i=50 90B14 H35VP90 50 90B14	24 mm	140 mm	90	50	B14 Flansa mica	La cerere
VP90 50 90B5	Reductor melcat 90 i=50 90B5 H35VP90 50 90B5	24 mm	200 mm	90	50	B5 Flansa mare	La cerere
VP90 60 80B14	Reductor melcat 90 i=60 80B14 H35VP90 60 80B14	19 mm	120 mm	80	60	B14 Flansa mica	La cerere
VP90 60 80B5	Reductor melcat 90 i=60 80B5 H35VP90 60 80B5	19 mm	200 mm	80	60	B5 Flansa mare	La cerere
VP90 60 90B14	Reductor melcat 90 i=60 90B14 H35VP90 60 90B14	24 mm	140 mm	90	60	B14 Flansa mica	La cerere
VP90 60 90B5	Reductor melcat 90 i=60 90B5 H35VP90 60 90B5	24 mm	200 mm	90	60	B5 Flansa mare	La cerere
VP90 7.5 100B14	Reductor melcat 90 i=7.5 100B14 H35VP90 7.5 100B14	28 mm	160 mm	100	7,5	B14 Flansa mica	La cerere
VP90 7.5 100B5	Reductor melcat 90 i=7.5 100B5 H35VP90 7.5 100B5	28 mm	250 mm	100	7,5	B5 Flansa mare	La cerere
VP90 7.5 90B14	Reductor melcat 90 i=7.5 90B14 H35VP90 7.5 90B14	24 mm	140 mm	90	7,5	B14 Flansa mica	La cerere
VP90 7.5 90B5	Reductor melcat 90 i=7.5 90B5 H35VP90 7.5 90B5	24 mm	200 mm	90	7,5	B5 Flansa mare	La cerere
VP90 80 80B14	Reductor melcat 90 i=80 80B14 H35VP90 80 80B14	19 mm	120 mm	80	80	B14 Flansa mica	La cerere
VP90 80 80B5	Reductor melcat 90 i=80 80B5 H35VP90 80 80B5	19 mm	200 mm	80	80	B5 Flansa mare	La cerere
VP90 80 90B14	Reductor melcat 90 i=80 90B14 H35VP90 80 90B14	24 mm	140 mm	90	80	B14 Flansa mica	La cerere
VP90 80 90B5	Reductor melcat 90 i=80 90B5 H35VP90 80 90B5	24 mm	200 mm	90	80	B5 Flansa mare	La cerere

Reductor melcat NMRW 90 i=25 100B5 H35

Caracteristici Reductor melcat NMRW 90 i=25 100B5 H35:

Gabarit: 10
Raport: i=25
Diametru ax motor: 28mm
Diametru flansa: 250mm
Tip flansa: B5-Flansa mare
Diametru ax iesire standard: H35mm
